The multi-channel tissue grinder is a special, fast, high-efficiency, multi-tube grinding system. Supports the extraction and purification of original DNA, RNA and protein from a variety of samples including soil, plant and animal tissues/organs, bacteria, yeast, fungi, spores, paleontological specimens, etc. Other substances can also be ground. Supports dry grinding, wet grinding and mixed grinding and homogenization. This product can support 24 different samples for grinding processing, improve grinding efficiency and quality, reduce labor costs, and reduce manual operation errors.
1. Suitable for grinding and crushing various plant tissues such as roots, stems, leaves, flowers, fruits and other samples
2. Suitable for grinding and crushing various animal tissues including brain, heart, lung, stomach, liver, bone, hair and other samples
3. Suitable for grinding and crushing samples of fungi and bacteria such as yeast and E. coli.
4. Suitable for grinding and crushing food and medicines
5. Suitable for grinding and crushing volatile samples such as coal, oil shale, wax products, etc.
6. Suitable for plastics, polymers, including PE, PS, textiles, resins, etc.
Technical parameters
| model | ZZYM-24 |
| LCD display | Microcomputer controls large-screen LCD to display working status |
| Adapter handling sample volume | 24 × (0.2 - 0.5 ML) / 16 × 2 ML / 8 × (7 - 10) ML / 8 × 15 ML / 4 × 25 ML / 2 × 50 ML |
| Standard configuration | Two adapters available |
| Homogenization speed | 10 - 70 Hz/sec |
| Shockproof principle | German technology schleifen-1 working method |
| Adapter material | PTFE or alloy steel |
| Grinding method | Wet grinding, dry grinding, low temperature grinding are all available |
| Large feed size | No requirement, adjust according to adapter |
| Final discharge particle size | 5µm |
| Number of grinding platforms | (Number of acceptable grinding jars) >2 |
| Fastening device with automatic centering | yes |
| Safety lock at work | Full protection |
| Grinding Kit Materials | Hard steel, polytetrafluoroethylene (Teflon) |
| power supply | Two-phase 220V/50HZ |
| working hours | 0 seconds to 99 minutes, user can set by himself; |
| Grinding ball diameter | 0.1 - 30 mm |
| Grinding ball material | Alloy steel, chromium steel, zirconia, tungsten carbide, quartz sand; |
| accelerate | Reach maximum speed in 2 seconds |
| slow down | Reach low speed in 2 seconds |
| Noise level | <50 dB |
| Overall dimensions | 280×400×530 |
| weight | 40 KG |
The multi-channel tissue grinder uses high-frequency vertical oscillation to select different grinding beads to grind samples with different properties directly in the centrifuge tube. The samples and grinding balls in the grinding tube collide with each other. The resulting grinding shear force and impact force completely break the tissue, thereby separating and extracting the original DNA and RNA.
1. You can place the centrifuge tube directly into the adapter, or you can pre-freeze the adapter.
2. The grinding process is fully enclosed, and samples move independently to avoid cross-infection.
3. Built-in program controller, parameter setting is simple and convenient
4. Adopt silent design to reduce interference to the surrounding environment
5. Equipped with a lock, which has the function of stopping when the cover is opened and has high safety.
6. Vertical oscillation, more complete grinding, and good consistency in grinding the same sample multiple times.
