It is used for mixing and scrubbing in laboratories of mining and scientific research departments such as geology, metallurgy, building materials, and chemicals, and is especially suitable for separating and selecting small amounts of mineral samples.
Technical parameters
| project | unit | GFX 5-35 | GFX 50-100 | |
| volume | ml | 20/60/100/140 | 200/400 | |
| capacity | gram | 5/15/25/35 | 50/100 | |
| Impeller speed | change /point | 0-2600 | 0-2600 | |
| Impeller diameter | mm | 18/26/26/30 | 36/ 48 | |
| Spindle motor | model |
| YS-5612 | YS-5612 |
|
| power |
| 220V/ 380/ 90W | 220V/ 380/ 120W |
|
| Speed | change /point | 2800 | 2800 |
| Feeding particle size | mm | 0.05-0.2 | 0.05-0.2 | |
1. The flotation speed is fast and the selection index is good.
2. Adjustment is convenient and accurate, and operation is reliable.
3. Analysis of low-grade ore and rare mineral samples.
4. The enrichment ratio requires a small amount of mineral samples to be carefully selected.
5. Inflatable hanging tank flotation machine (optional), the hollow shaft is designed with large inflation volume, central inflation, and stepless speed regulation by frequency converter.
Parameters
| Model | GFX |
|---|---|
| Grinding Jar Capacity | |
| Feed Size | |
| Output Size | |
| Speed | |
| Power | |
| Voltage | |
| Dimensions | |
| Weight | 0 |
Related Videos
The trusted choice of industry leaders
FAQ
-
What is a Hanging Tank Flotation Machine? A Laboratory Flotation Device for Selective Mineral Separation
A hanging tank flotation machine is a lab-scale flotation device used for mineral separation, agitation, and scrubbing of small ore samples. It mimics industrial froth flotation to separate valuable minerals from gangue based on surface hydrophobicity. Ideal for geological, metallurgical, and research labs, it features interchangeable hanging tanks and adjustable impeller speeds for precise flotation testing.
MORE >> -
What is an Experimental Flotation Machine? A Laboratory Device for Mineral Separation Research and Beneficiation Testing
An experimental flotation machine is a specialized laboratory device used to simulate the industrial flotation process for mineral separation, beneficiation research, and ore washability testing. It works by agitating ore pulp and air to form bubbles, allowing hydrophobic valuable minerals to attach and float while gangue sinks. Key features include adjustable impeller speed, aeration, and multi-cell configurations for batch testing. This guide covers its working principle, main types (mechanical agitation, aeration, hanging tank), selection criteria, and applications in geology, metallurgy, coal, and chemical industries.
MORE >> -
What is a Hanging Tank Flotation Machine? A Laboratory Flotation Device for Mineral Separation
Discover the definition, working principle, types, and key selection criteria of hanging tank flotation machines. This guide explains how these laboratory devices separate minerals by froth flotation, ideal for research, mining, and metallurgy labs.
MORE >>
